Muscat Centrifugal Pumps
Motor
• 2-pole induction motor, 50 Hz (n = 2900 RPM)
• Single phase 230V +5% -15% with thermal protection.
• Insulation class B.
• Protection IP 44.
• Constructed in accordance with IEC 34.
• Available in 60 Hz.
Special Features on Request
• Other voltages.
• Available in three phase.
• Available stainless steel or brass impeller.
• Special mechanical seal.
• Higher liquid or ambient temperatures.
Direction of rotation
Clockwise as seen from the motor rear end.
Construction
• The VM pumps are non self priming, horizontal, single-stage,
centrifugal pumps.
• Motor and pump are close coupled in a convenient and compact
design for quick installation in limited space.
• The pump is fitted with a maintenance-free, mechanical shaft seal.
• The pumps have axial suction port and radial discharge port.
Applications
• For clean liquids without abrasives, which are non-aggressive for
the pump materials. (solids content up to 0.2%)
• For water supply.
• For heating, cooling, air-conditioning and circulation plants.
• For civil and industrial applications.
• As pressure boosting pumps for central water systems.
• For irrigation.
• For circulation plants.
• For washing with a jet of water.
Operating Conditions
• Liquid temperature up to 90°C.
• Ambient temperature up to 40°C.
• Total suction lift up to 8 m.
• Continuous duty.
